2 in 1 0.3-1.5 mm coil feeding line: high precision thin plate decoiller and straightening

Model:
GJK series

Usage range:
Suitable for 0.3-1.5mm thickness sheet thickness coil uncoiler, straightener & feeder for kitchen hardware

suitable material is stainless steel, copper, aluminum....

Advantages:

1, the uncoiler and precision plate leveling machine optimization together, suitable for 0.3 ~ 1.5mm the plate for stainless steel plate, copper plate, aluminum plate and higher precision products leveling.
2, the upper roller board can lift type 45 degrees, easy for roller cleaning and maintenance, completely avoid the scratch of sheet materials.
3, leveling roller adopts independent transmission,up 9/ bottom 9 structure, with up leveling roller with auxiliary roller, it can adjuste the material bending direction according to requirement, the entire drive correction design, in order to improve the flatness of the plate surface, suitable for high precision machining requirements.
4, the drum is adjusted by the original score type adjustment mode instead of the traditional dial type regulating mode, without additional correction, debugging is more simple and accurate, longer service life.
5, leveling rollers uses bearing steel (SUJ2), after heat treatment, HRC60 degrees surface plating hard chromium, and then grinding, high hardness, high wear resistance, long life.
6, the machine adopts dual inverter control, can reduce scratch caused by initiating material , reduce the damage rate.
7, for long size materials, shear line can also be used.

2 in 1 Machine Models:

WxiJiniu Machinery Co.,ltd. formerly known as Wuxi Metallurgical Machinery Factory, registered trademark for "Jinqiu" brand, was founded in June 1969. It is in Wuxi city, 150 kilometers far from Shanghai city. We have been to stated enterprise, since 2002, we recombined to private company, and got fast development, we are one big group now, our group mainly produces hydraulic press brake, hydraulic shears, coiling feeding line--especially for aluimnum cap making, slitting line, cut to length, transformer machines....and other series product. It is one of the earliest factory in China to make these metal sheet machines.

The company covers an area of 62,000 square meters with 300 people. It has advanced production equipment’s with imported large CNC gantry milling machine, imported large CNC boring and milling machine, 100-ton carriageway and a series of iconic devices. Our excellent design team can make personalized products according to the users’ demands. At the same time, we have established long-term cooperation with some famous university, such as Jiangnan university, Nanjing University, Jiangsu University. Through our research staff innovation and hard work, we have received dozens of patents. At the same time, we have ISO and CE certifications.

In the domestic market, we set up many offices in different cities, Beijing, Kunming, Hefei…And to the international market, in many countries, we have sales and service agent, USA, Peru, Brazil, India, Russia…. Our engineers have been to those countries to install our machines. Because of our machine good quality and good after-sales service, the customers give us very high commend.

We hope to set up very good and long cooperation with more customers around the word.
